Product Description
The Spanet V2 Spa Controller is a robust spa control system designed for residential hot tubs and spas operating on 230–240V single‑phase power. Engineered for reliability and electrical safety, the V2 provides stable control of spa heating and pump functions while meeting Australian and international compliance standards.
This control system supports heaters up to 3.0kW and pump loads up to 13 amps, making it suitable for a wide range of standard spa configurations. The enclosure is rated IPX5, offering protection against water jets and moisture commonly present in spa cabinet environments.
Built and approved in accordance with AS/NZS and IEC safety standards, the Spanet V2 is intended for installation and servicing by qualified technicians only. Clear warning labelling highlights the presence of dangerous voltages inside the unit.
Technical Specifications
- Model: Spanet V2
- Supply Voltage: 230–240V AC, 50/60Hz
- Output Voltage: 240–250V AC
- Maximum Pump Current: 13A
- Maximum Heater Phase Current: 15A per phase
- Heater Rated Power: 3000W (3.0kW)
- Frequency: 50–60Hz
- IP Rating: IPX5
-
Compliance Standards:
- EN60335 / IEC60335‑2‑60
- AS/NZS 3100
- Application: Spa / Hot Tub Control System
Controller Dimensions.
Length: 544mm
Height: 309mm
Width: 90mm
Weight: 5kg
