Product Description
The LX Whirlpool TDA100 Spa Pump is a reliable 1.0HP single‑speed pump designed for spa and hot tub circulation and light jet applications. Operating on a 50Hz power supply, it is ideal for Australian spa systems and is commonly used as a replacement pump in residential and commercial spas.
Built by LX, a trusted global manufacturer of spa pumps, the TDA100 delivers consistent water flow, quiet operation, and dependable performance. Its compact design makes it suitable for tight equipment bays while still providing efficient circulation and jet support.
This pump is widely used for filtration, heating circulation, and low‑to‑medium flow massage applications.
Technical Specifications
- Pump Model: LX Whirlpool TDA100
- Pump Type: Spa / Hot Tub Pump
- Motor Power: 1.0 HP
- Speed: Single Speed
- Frequency: 50Hz
- Voltage: 220–240V
- Phase: Single Phase
- Current (Approx.): ~4.5–6.0A
- Flow Application: Circulation / light massage
- Connection Size: 2″ inlet / 2″ outlet (standard spa unions)
- Pump Orientation: Side discharge, centre suction
- Motor Frame: 48 Frame
- Cooling: Air‑cooled motor
- Insulation Class: Class F
- Thermal Protection: Built‑in thermal overload protection
- Seal Type: Mechanical carbon/ceramic shaft seal
- Duty Use: Continuous
- Manufacturer: LX Whirlpool
Applications
- Spa and hot tub water circulation
- Filtration and heating loops
- Low‑flow massage jet systems
- Replacement for compatible LX single‑speed spa pumps
⚠️ Important:
Installation should be performed by a qualified technician. Always confirm plumbing size, electrical ratings, and pump orientation before ordering to ensure compatibility with your spa system.
